A linear profile sander for four-side sanding of shaped wood mouldings. Sanding frames are suitable for long straight workpieces
| Category | Parameters |
|---|---|
| Sanding Process | Raw wood or primer |
| Working Width | 30–220 mm |
| Min. Working Length | 600mm |
| Max. Working Thickness | 70mm |
| Feeding Speed | 10–35 m/min |
| Working Air Pressure | 0.6–0.8 MPa |
| Working Voltage | 380V / 50Hz |
| Total Power | 23.5 kW |
| Overall Dimensions (L×W×H) | 6000×2100×1500 mm |
Shaped wood mouldings pass through the machine for four-side sanding.
Sanding is performed by the movement of abrasive belts, which provides the best flatness for workpieces and can sand shorter profiled parts.
Sanding heads offer strong adaptability, capable of mounting various abrasives for different shapes. Suitable for raw wood sanding,
primer sanding and other processes.
Sanding frames and sanding heads each have their advantages: frames are ideal for flatness sanding of long straight workpieces,
while heads are suitable for multi-angle sanding of profiled parts. Customers can flexibly select frame or head configurations, or combine both, based on their product shapes and process requirements.
The machine supports multiple sanding processes: UV fully-closed primer, open-type primer, raw wood, etc. Different materials and coating processes can use different abrasive belt grits and sanding methods, such as raw wood sanding, primer sanding, and polishing.
